Welcome to ITO Coatings

ITO Coatings forms part of Diamond Coatings Ltd. Established in 2002, Diamond Coatings Ltd operates from ultra-modern vacuum coating plants in both the UK & the USA and has over the years grown into an industry-leading manufacturer/supplier of specialist Indium Tin Oxide (ITO) and Optical Coatings.

Leading Supplier of ITO Coated Products, Anti-Reflective Coatings, Special Optical Coatings & Beam Splitters.

Servicing a worldwide customer base, Diamond Coatings Ltd supply a wide range of ITO coated products to an extensive range of markets, including:
Aerospace • Automotive • Entertainment • Imaging & Microscopy • Medical • Military & Defence • Research & Development • Space
Available products include, among others:
Capacitive Switches • Conductive Tapes • Conductive PET Films • Heater Windows • ITO (Indium Tin Oxide) & AR (Anti-Reflection) Coatings • ITO Glass • ITO Plastic • Microscope Coverslips & Slides • Plastic & Glass Supply with Optional Hard Coatings • Touchscreens • RFI Shielding Filters

We supply a wide range of ITO coated products to an extensive range of markets worldwide

Recent

News

Visin

Anti-Reflective Face Shields

Light Transmission
89%
Light Transmission
97%

Our Anti Reflective Face shields are coated with our custom Anti-Reflective coatings. 97% light transmission compared to 89%. Virtually zero reflection from either side.

The UK-made face shield is created from medical grade materials and is fully certified to BS EN166:2002.

Questions? Please contact us

If you have any questions about ITO Coatings or the services and products we supply, please get in touch

ITO Anti-Reflective Coatings

Offering spectral properties similar to those of DIAMOX + coatings, our Anti-Reflective Coatings are available on glass, acrylic and polycarbonate substrates with part sizes up to 700 mm x 700 mm. Offering a typical sheet resistance of 1000+ ohms/sq, these conductive AR Coatings are available in the following options:

DIAMOND-AR A multi-purpose coating suitable for varying customer requirements.

DIAMOND-AR WET An acrylic sheet dipped with AR coating offering approximately 3% of reflection.

DIAMOND-AR VAC A vacuum deposited AR coating at varying wavelengths and average 0.5% of reflection to suit a range of customer requirements.

DIAMOND-AR COND A conductive ITO coating and multilayer AR combination.

Special Optical Coatings & Beam Splitters

We offer a comprehensive selection of high quality Special Optical Coatings & Beam Splitters within the infra-red and optical ranges, using semiconductor & oxide layers with wavelengths ranging between 300 nm and 20 microns. Available on substrates including an extensive glass range, optical polymers, and sapphire, we offer optical coating and beam splitter options for parts sized up to 700 mm x 700 mm including:
  • All coatings available in Near Infra-Red, Infra-Red and Visible Ranges
  • Anti Reflection (AR) Coatings (Broadband and V Coats) providing extremely efficient AR with reflections under 0.5%.
  • Beam Splitters with varying Transmission/Reflection values (i.e. 70/30 or 50/50 +/- 1.5%)
  • Front Surface Mirrors with reflection exceeding 99%
  • Infra-Red Blocking Filters (or Hot Mirrors)
  • Edge, Bandpass & Narrow Band Filters

Other Coatings

Operating state-of-the-art, clean room-equipped vacuum coating plants that were specifically designed & built to meet our own specifications, we work with global research & design institutions and industry-leading companies to provide premium quality Special Optical Coatings, Beam Splitters & Anti-Reflective Coatings, as well as a wide range of other high-quality products including:
